MYMSM72TM-HC-TCN 565-580W TOPCon N Type

ADVANCED TECHNOLOGY PROVIDING HIGH EFFICIENCY
Minimum loss in shadowing and maximum power production with TOPCon N type Monocrystalline 144 Half Cut cell technology

EXTRA POWER WITH BIFACIAL TECHNOLOGY
Up to 25% extra power generation with back surface

HIGH RESISTANCE TO THE MOST DIFFICULT WEATHER CONDITIONS
The strongest winds (2,400 Pa) and the heaviest snowfalls
(5,400 Pa) high durability

12-year product warranty / 30-year performance warranty

Advanced Technology Providing High Efficiency

TOPCon N type Monocrystalline 144 pcs

EXTRA POWER WITH BIFACIAL TECHNOLOGY

Up to 25% extra power generation with back surface

High Durability in the Toughest Weather Conditions

High resistance to the strongest winds (2,400 Pa) and the heaviest snowfalls (5,400 Pa).

ELECTRICAL SPECIFICATIONS

Module Type	MYMSM72TM-HC-TCN 565W		MYMSM72TM-HC-TCN 570W		MYMSM72TM-HC-TCN 575W		MYMSM72TM-HC-TCN 580W
	STC (Ön)	STC (Arka)	STC (Ön)	STC (Arka)	STC (Ön)	STC (Arka)	STC (Ön)	STC (Arka)
Maximum Power (Pmax) (W)	565	452	570	456	575	460	580	464
Open Circuit Voltage (Voc)	51.5 V	51.5 V	51.7 V	51.7 V	51.9 V	51.9 V	52.1 V	52.1 V
Short Circuit Current (Isc)	13.89	11.11	13.95	11.16	14.01	11.21	14.07	11.26
Maximum Power Voltage (Vmp)	42.8 V	42.8 V	43.0 V	43.0 V	43.2 V	43.2 V	43.4 V	43.4 V
Maximum Power Current (Imp)	13.21	10.57	13.26	10.61	13.32	10.66	13.37	10.70
Module Efficiency	%21.86		%22.06		%22.25		%22.44
Power Tolerance	(0, +4.99)
Maximum System Rated Voltage	1500 V DC
Maximum Series Fuse Current	25 A
*Measurement Tolerance +/- 3%	STC: Irradiance 1000W/m2, Cell Temperature 25°C, AM=1.5

BACK FACE POWER GAIN VALUES

Power Gain	10%	15%	20%	25%	30%
Maximum Power (Pmax) (W)	621	648	675	702	729
Open Circuit Voltage (Voc)	51.5	51.5	51.5	51.5	51.5
Short Circuit Current (Isc)	15.28	15.98	16.67	17.36	18.06
Maximum Power Voltage (Vmp)	42.8	42.8	42.8	42.8	42.8
Maximum Power Current (Imp)	14.53	15.19	15.85	16.51	17.17
*Based on MYMSM72TM-HC-TCN 565W.

MECHANICAL SPECIFICATIONS

Panel Size (mm)	2279x1134x35
Weight (kg)	31
Cell Size (mm)	182x91
Number of Cells (pcs)	144 (12x12)
Max. Wind/Snow Load Resistance (Pa)	2400/5400
Junction Box Protection Class	IP68 3 Diode MC4 Compatible
Junction Box Cable Length (mm)	350-1600

TEMPERATURE CHARACTERISTICS

Pmax Temperature Coefficient	-0.29 %/°C
Voc Temperature Coefficient	-0.25%/ºC
Isc Temperature Coefficient	+0.05 %/°C
Operating Temperature	-40~+85°C

PACKAGING

Container	20' GP	40' HQ
Pieces Per Pallet	35	31
Pallet Per Container	4	20
Pieces Per Container	140	620

I-V CURVE
